W10408179 for Whirlpool Kenmore Kitchenaid Refrigerator Water Valve for 4389177

Description

Exact Replacement Water Valve for Whirlpool; part number W10408179

This valve is factory tested with water pressure so it may contain some water when received…. that is normal…please allow to air dry and there will be no harm done electrically

This Ice-maker Water Fill Valve is a Double Coil Valve designed to replace “in the grill filter” water valves

This valve has 2 Coils, 1 Green, 1 Red. The Green coil has 3/16″ male terminals, The Red coil has 1/4″ male terminals. The sticker on it reads 120V # 2188708, W1=35W, W2=20W

It has 3 water lines that attach to it, 1 inlet & 2 outlets

A section of tubing & a fitting are included

Replaces numbers 2186486, 2188622, 2188746, 2205762, 2255457, 2304757, 2315534, 4389177, AP3160649, AP5263471, PS733408, and PS3497634

This is designed to fit specific Whirlpool manufactured refrigerator models including KitchenAid, Roper, Estate, Kirkland and Kenmore
